Z09 wireless signal converter main function is to forward the detector signal to the alarm host, indirectly, extend the detector to send the distance, expand the alarm control range. For the host and the detector far away or the middle of the obstacles caused by the transmission and receptionof signals is not ideal occasions
1. Five wireless zones 1-5 zone, the wireless detector can learn the code to the relay of the five wireless zones, each
zone detector number is limited but the total number of zone detectors no more than 99.
2.Can learn remote control remote control signal, up to learn 99 remote control.
3.Two wired zones Z4-Z5 zone, wired zone Optional short circuit alarm or open circuit alarm (NO or NC).
4. Compatible with millions of chips 1527 (resistance 150K-470K) and ordinary coding chip 2262 (resistance 1.5M-4.7M) full range of remote control and detectors.
5.Built-in rechargeable battery, an external power supply trickle charge, external power supply automatically switch
battery power.
6..Built-in EEPROM chip, in the case of shutdown or power failure, learning the code on the remote control and detectors and other information will not be lost to ensure information security
External power supply: DC5V or DC12V;
2. Built-in battery: Ni-Hi DC 4.2V
3. Quiescent current: <20mA / DC 5V or <13mA / DC 12V
4. Operating current: <500mA / DC 5V or <100mA / DC 12V
5. Receive, detection frequency: 433 MHz (ASK) / 868MHz
(FSK)
6. Learn the maximum number of remote controls: 99
7. Learn the maximum number of wireless detectors: 99
8. Received detection distance: 100M or so (open ground)
9. Send distance: 500M or so (open)
10. Working temperature: -20 ℃ -55 ℃
Wireless signal transfer repeater Z09 *1
Power adapter *1
User guide *1
