Specification
|
|
|
|
|
Protocols/Standards
|
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR),DHCP, PPPoE, SSH, TFTP, NTP, STUN,SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP
|
|
|
Networking Interfaces
|
Dual switched auto-sensing 10/100 Mbps Ethernet ports, integrated PoE (GXP1625 only)
|
|
|
|
|
Graphical Display
|
132 x 48 backlit graphical LCD display
|
|
|
|
|
Feature Keys
|
2 line keys with dual-color LED and 2 SIP accounts, 3 XML programmable context sensitive soft keys, 5(navigation, menu) keys. 13 dedicated function keys for MUTE, HEADSET, TRANSFER, CONFERENCE,SEND and REDIAL, SPEAKERPHONE, VOLUME, PHONEBOOK, MESSAGE, HOLD, PAGE/INTERCOM,RECORD, HOME
|
|
|
|
|
Voice Codecs
|
Support for G.711μ/a, G.722 (wide-band), G.723 (pending), G.726-32, G.729 A/B, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC
|
|
|
|
|
Telephony Features
|
Hold, transfer, forward (unconditional/no-answer/busy), 3-way conferencing, call park/pickup, shared-call appearance (SCA) / bridged-line-appearance (BLA), Downloadable phone book (XML, LDAP, up to 500 items), call waiting, call history (up to 200 records), off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones, server redundancy & fail-over
|
|
|
|
|
Headset Jack
|
RJ9 headset jack (allowing EHS with Plantronics headsets)
|
|
|
|
|
Base Stand
|
Yes, 2 angled positions available, wall mountable
|
|
|
|
|
Wall Mountable
|
Yes
|
|
|
|
|
QoS
|
Layer 2 (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
|
|
|
|
|
Security
|
User and administrator level passwords, MD5 and MD5-sess based authentication, AES based secure configuration file, SRTP, TLS,
802.1x media access control
|
|
|
|
|
Multi-language
|
English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese,etc
|
|
|
|
|
Upgrade/Provisioning
|
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or encrypted XML configuration file
|
|
|
|
|
Power & Green Energy Efficiency
|
Universal Power Supply Input 100-240VAC 50-60Hz; Output +5VDC, 600mA
PoE: ieee802.3af Class 2, 3.84W-6.49W (GXP1625 only)
|
|
|
|
|
Physical
|
Dimension: 209mm (L) x 184.5mm (W) x 76.2mm (H) (with handset)
Unit weight: 0.73kg; Package weight: 1.1kg
|
|
|
|
|
Operating Temperature & Humidity
|
Operation: 0°C to 40°C, Storage: -10°C to 60°C , Humidity: 10% to 90% Non-condensing
|
|
|
|
|
Package Content
|
GXP1620/1625 phone, handset with cord, base stand, universal power supply, network cable, Quick Installation Guide, brochure, GPL License
|
|
|
|
|
Compliance
|
FCC: Part 15 (CFR 47) Class B
CE : EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN60950-1
RCM: AS/ACIF S004; AS/NZS CISPR22/24; AS/NZS 60950; AS/NZS 60950.1
|
